MCMILLAN AIR COMPRESSOR ABAC 3 PHASE 415V 4HP 125L TANK MADE IN AUSTRALIA AF49

Description AF Series – 415V Our industrial range of stationary air compressors available from 4 to 10Hp using pumps from the world’s largest air compressor manufacturer, ABAC SpA, offering reliable, affordable units with full after sales service. Air compressor tanks made to Australian Standard AS1210. ABAC two stage pumps are far more efficient than single stage pumps where required pressure is 100psi and above. Rated to AS4637. Efficient two stage, Italian made ABAC pump. Cast iron cylinder and crankshaft. Two stage, 160psi for high pressure applications. Intercooler & aftercooler for cooler, drier air. NEMA auto stop/start pressure switch. Guard design for fan forced cooling. Less power usage – cheaper to run. Motor overload protection. Full range of spare parts available. Warranty. 2 years on pump. 5 years on tank. 1 year on motor and fittings. Product Code Displacement Free Air Delivery Motor Tank Pump Model Cylinders / Stages Max. Pressure CFM L/min CFM L/min HP Litres psi AF 49 18.0 509 14.8 419 4.0 125 B4900 2/2 Stage 160 AF 59 23.0 651 18.4 521 5.5 155 B5900 2/2 Stage 160 AF 60 29.2 826 23.3 659 7.5 155 B6000 2/2 Stage 160 AF 60/L 29.2 826 23.3 659 7.5 300 B6000 2/2 Stage 160 AF 70 42.7 1208 34.2 968 10.0 300 B7000 2/2 Stage 160   Weight Dimensions Kgs Width Length Height 135 450 1450 890 176 430 1500 930 209 430 1500 960 316 680 1550 1120 329 680 1550 1164
